18 layer 3step HDI PCB refers to the HDI circuit board with more than 2 levels, usually 3 + N + 3 or 4 + N + 4 or 5 + N + 5 structure. The blind hole uses a laser, and the hole copper is about 15UM.The following is about 18 layer 3step HDI circuit board related, I hope to help you better understand 18 layer 3step HDI circuit board.
Quick Details of 18 layer 3step HDI circuit board
Place of Origin:Guangdong, China
Brand Name:18 layer 3step HDI PCB Model Number:Rigid-PCB
Base Material:Isola
Copper Thickness:1oz Board Thickness:2mm
Min. Hole Size:0.075mm Min. Line Width:1.9mil Min. Line Spacing:1.9mil
Surface Finishing:ENIG
Number of layers:32L PCB Standard:IPC-A-600
Solder Mask:Green
Legend:White
Product quotation:Within 2 Hours
Service:24Hours technical services Sample delivery:Within 14 days
HONTEC Quick Electronics Limited (HONTEC), established in 2009, is one of leading quickturn Printed Circuit Board manufacturer, who specializes in high-mix, low volume and quickturn prototype PCB for high-tech industries in 28 countries. Upon efficiently quick around operation, PCB products contain 4 to 48 layers, HDI, Heavy Copper, Rigid-Flex, high frequency microwave,and Embedded Capacitance, and provides "PCB One-stop Shop" service to meet customers’ diverse demands. HONTEC is capable of producing 4,500 varieties monthly to meet 24-hour delivery for 4 layers PCB, 48-hour for 6 layers and 72-hour for 8 or more high-layer PCB at the fastest. Located in SiHui of GuangDong,HONTEC partners up with UPS, DHL and world-class forwarders to provide efficient shipping services.
