HDI imaging, while achieving low defect rate and high output, can achieve stable production of HDI conventional high-precision operation. For example: advanced mobile phone board, CSP pitch is less than 0.5mm. The board structure is 3 + n + 3, there are three superposed vias on each side, and 6 to 8 layers of coreless printed boards with superimposed vias.The following is about Medical Equipment HDI PCB related, I hope to help you better understand Medical Equipment HDI PCB.
Quick Details of Medical Equipment HDI PCB
Place of Origin:Guangdong, China
Brand Name:Network equipment PCB Model Number:Rigid-PCB
Base Material:TUC
Copper Thickness:1oz Board Thickness:3.0mm
Min. Hole Size:0.1mm Min. Line Width:2.5mil Min. Line Spacing:2.5mil
Surface Finishing:ENIG
Number of layers:28L PCB Standard:IPC-A-600
Solder Mask:Green
Legend:White
Product quotation:Within 2 Hours
Service:24Hours technical services Sample delivery:Within 18 days
HONTEC Quick Electronics Limited (HONTEC), established in 2009, is one of leading quickturn Printed Circuit Board manufacturer, who specializes in high-mix, low volume and quickturn prototype PCB for high-tech industries in 28 countries. Upon efficiently quick around operation, PCB products contain 4 to 48 layers, HDI, Heavy Copper, Rigid-Flex, high frequency microwave,and Embedded Capacitance, and provides "PCB One-stop Shop" service to meet customers’ diverse demands. HONTEC is capable of producing 4,500 varieties monthly to meet 24-hour delivery for 4 layers PCB, 48-hour for 6 layers and 72-hour for 8 or more high-layer PCB at the fastest. Located in SiHui of GuangDong,HONTEC partners up with UPS, DHL and world-class forwarders to provide efficient shipping services.
