The XCVU065-2FFVC1517I device provides optimal performance and integration at 20nm, including serial I/O bandwidth and logic capacity. As the only high-end FPGA in the 20nm process node industry, this series is suitable for applications ranging from 400G networks to large-scale ASIC prototype design/simulation.
The XCVU065-2FFVC1517I device provides optimal performance and integration at 20nm, including serial I/O bandwidth and logic capacity. As the only high-end FPGA in the 20nm process node industry, this series is suitable for applications ranging from 400G networks to large-scale ASIC prototype design/simulation.
application
4x100G Repeater
400G MAC - Interlaken Bridge
2x100G multiplexing repeater
400G OTN Switch (POTS)
ASIC Prototype&Simulation
Product attributes
Device: XCVU065-2FFVC1517I
Product type: FPGA - Field Programmable Gate Array
Series: XCVU065
Number of logic components: 783300 LE
Adaptive Logic Module - ALM: 44760 ALM
Embedded memory: 44.3 Mbit
Number of input/output terminals: 560 I/O
Power supply voltage - minimum: 950 mV
Power supply voltage - maximum: 950 mV
Minimum working temperature: -40 ° C
Maximum working temperature:+100 ° C
Data rate: 6 Gb/s
Number of transceivers: 40
Installation style: SMD/SMT
Package/Box: BGA-1517
Distributed RAM: 4.8 Mb
Number of logical array blocks - LAB: 44760 LAB
Working power supply voltage: 950 mV
