Power amplifier PCB-The role of the power amplifier is to amplify the weak signal from the sound source or pre-amplifier, and promote the speaker to play sound. The function of a good sound system amplifier is indispensable.The following is about Microwave circuit board related, I hope to help you better understand Microwave circuit board.
The F4B Antenna PCB includes a core board provided with a hollow groove and a copper-clad plate adhered to the upper and lower surfaces of the core board by flow glue, and edges of the upper and lower openings of the hollow groove are provided with ribs.The following is about Antenna circuit board related, I hope to help you better understand Antenna circuit board.
Hard gold PCB--plating gold can be divided into hard gold and soft gold. Because the hard gold plating is an alloy, the hardness is relatively hard. It is suitable for use in places where friction is required. It is generally used as a contact point on the edge of the PCB (commonly known as gold fingers).The following is about Hard gold plated PCB related, I hope to help you better understand Hard gold plated PCB.
2.5G optical module PCB--The function of the optical module is photoelectric conversion. The transmitting end converts the electrical signal into an optical signal. After transmission through the optical fiber, the receiving end converts the optical signal into an electrical signal.The following is about 2.5G Optical Module PCB related, I hope to help you better understand 2.5G Optical Module PCB.
HDI is the abbreviation of High Density Interconnector. It is a kind of technology for the production of printed circuit boards. It is a circuit board with a relatively high line distribution density using micro-blind buried via technology.The following is about IPAD HDI PCB related, I hope to help you better understand IPAD HDI PCB.
Teflon PCB (also called PTFE board, Teflon board, Teflon board) is divided into two kinds of molding and turning. The molding board is made of PTFE resin at room temperature by molding, and then sintered, Made by cooling. The PTFE turning plate is made of PTFE resin through compacting, sintering and rotary cutting.
