The Rigid-Flex PCB has the characteristics of FPC and PCB. Therefore, it can be used in some products with special requirements. It has not only a certain flexible area, but also a certain rigid area, which is of great help to save the internal space of the product, reduce the volume of the finished product, and improve the performance of the product.
Multilayer PCB circuit board--The manufacturing method of multilayer board is generally made by the inner layer pattern first, and then the single or double-sided substrate is made by printing and etching method, which is included in the designated interlayer, and then heated, pressurized and bonded. As for the subsequent drilling, it is the same as the plating through-hole method of double-sided plate. It was invented in 1961.
In the design of 13 layer R5775G high-speed PCB, the main problems that must be considered are signal integrity, electromagnetic compatibility and thermal noise. Generally, when the signal frequency is higher than 30MHz, the signal distortion must be prevented. When the frequency is higher than 66MHz, the signal integrity must be analyzed.
Rogers antenna PCB has high dielectric constant, large loss and good heat dissipation, so it is widely used in high-power and small-volume devices.The following is about GE Rogers antenna , I hope to help you better understand GE Rogers antenna .
PTFE multilayer PCB--Agilent equipment provides customers with products for optical networks, transmission networks, broadband and data networks, wireless communication and microwave network types of networks and systems.The following is about Agilent equipment, I hope to help you better understand Agilent equipment.
24G High frequency PCB--24GHz microstrip array antenna, select 10mil or 20mil thickness for small array, 20mil thickness for large array, and 10mil thickness for RF board.The following is about 24G High frequency PCB, I hope to help you better understand 24G High frequency PCB.
