Multilayer Ceramic PCB substrate refers to a special process board where copper foil is directly bonded to the surface (single side or double side) of alumina (Al2O3) or aluminum nitride (AlN) ceramic substrate at high temperature. The following is about Multilayer Ceramic Circuit Board related, I hope to help you better understand Multilayer Ceramic Circuit Board PCB.
Quick Details of Multilayer Ceramic Circuit Board
Place of Origin:Guangdong, China
Brand Name:Multilayer Ceramic PCB Model Number:Rigid-PCB
Base Material:Alumina
Copper Thickness:1oz Board Thickness:1mm
Min. Hole Size:0.2mm Min. Line Width:6mil Min. Line Spacing:6mil
Surface Finishing:ENIG
Number of layers:2L PCB Standard:IPC-A-600
Solder Mask:White
Legend:Black
Product quotation:Within 2 Hours
Service:24Hours technical services Sample delivery:Within 10 days
HONTEC Quick Electronics Limited (HONTEC), established in 2009, is one of leading quickturn Printed Circuit Board manufacturer, who specializes in high-mix, low volume and quickturn prototype PCB for high-tech industries in 28 countries. Upon efficiently quick around operation, PCB products contain 4 to 48 layers, HDI, Heavy Copper, Rigid-Flex, high frequency microwave,and Embedded Capacitance, and provides "PCB One-stop Shop" service to meet customers’ diverse demands. HONTEC is capable of producing 4,500 varieties monthly to meet 24-hour delivery for 4 layers PCB, 48-hour for 6 layers and 72-hour for 8 or more high-layer PCB at the fastest. Located in SiHui of GuangDong,HONTEC partners up with UPS, DHL and world-class forwarders to provide efficient shipping services.
