HONTEC is one of leading Multilayer Board manufacture, who specializes in high-mix,low volume and quickturn prototype PCB for high-tech industries in 28 countries.
Our Multilayer Board has passed UL, SGS and ISO9001 certification, we are in application of ISO14001 and TS16949 as well.
Located in Shenzhen of GuangDong, HONTEC partners up with UPS, DHL and world-class forwarders to provide efficient shipping services. Welcome to buy Multilayer Board from us. Every request from customers is being replied within 24 hours.
The unmanned aerial vehicle is referred to as "UAV" for short, or "UAV" for short. It is an unmanned aircraft operated by radio remote control equipment and self-provided program control device, or it is operated completely or intermittently by an on-board computer.The following is about Large size Drone PCB related, I hope to help you better understand Large size Drone PCB.
The via-in-PAD is an important part of the multilayer PCB. It not only bears the performance of the main functions of the PCB, but also uses the via-in-PAD to save space.The following is about VIA in PAD PCB related, I hope to help you better understand VIA in PAD PCB.
Buried vias: Buried vias only connect the traces between the inner layers, so they are not visible from the PCB surface. Such as 8layer board, the holes of 2-7 layers are buried holes.The following is about Mechanical Blind Buried Hole PCB related, I hope to help you better understand Mechanical Blind Buried Hole PCB.
Thick copper board are mainly high-current substrates. High-current substrates are generally high-power or high-voltage substrates, which are mostly used in automotive electronics, communications equipment, aerospace, planar transformers, and secondary power modules.The following is about New energy car 6OZ Heavy copper PCB related, I hope to help you better understand New energy car 6OZ Heavy copper PCB.
Hard gold PCB--plating gold can be divided into hard gold and soft gold. Because the hard gold plating is an alloy, the hardness is relatively hard. It is suitable for use in places where friction is required. It is generally used as a contact point on the edge of the PCB (commonly known as gold fingers).The following is about Hard gold plated PCB related, I hope to help you better understand Hard gold plated PCB.
Gold finger PCB In the extensive use of PCI cable socket gold fingers, gold fingers have been divided into: long and short gold fingers, broken gold fingers, split gold fingers, and gold finger boards. In the process of processing, gold-plated wires need to be pulled. Comparison of conventional gold finger processing processes Simple, long and short gold fingers, the need to strictly control the lead of the gold fingers, requires a second etching to complete.The following is about Gold finger Board related, I hope to help you better understand Gold finger Board.
