HONTEC is one of leading High-speed Board manufacture, who specializes in high-mix,low volume and quickturn prototype PCB for high-tech industries in 28 countries.
Our High-speed Board has passed UL, SGS and ISO9001 certification, we are in application of ISO14001 and TS16949 as well.
Located in Shenzhen of GuangDong, HONTEC partners up with UPS, DHL and world-class forwarders to provide efficient shipping services. Welcome to buy High-speed Board from us. Every request from customers is being replied within 24 hours.
EM-888 7MM Thick PCB--As user applications require more and more board layers, alignment between layers becomes very important. Alignment between layers requires tolerance convergence. As the board size changes, this convergence requirement is more demanding. All layout processes are generated in a controlled temperature and humidity environment. The following is about EM888 7MM Thick PCB related, I hope to help you better understand EM888 7MM Thick PCB.
Tachyon 100G PCB The exposure equipment is in the same environment. The alignment tolerance of the front and back images of the entire area must be maintained at 0.0125mm. The CCD camera is required to complete the front and rear layout alignment. After etching, the four-hole drilling system was used to perforate the inner layer. The perforation passes through the core board, the position accuracy is maintained at 0.025mm, and the repeatability is 0.0125mm. The following is about Tachyon 100G High-speed PCB related, I hope to help you better understand Tachyon 100G High-speed PCB.
In addition to the requirement for uniform thickness of the plating layer for drilling, backplane designers generally have different requirements for the uniformity of copper on the surface of the outer layer. Some designs etch few signal lines on the outer layer. The following is about Megtron6 step PCB related, I hope to help you better understand Megtron6 step PCB.
It is generally believed that if the frequency of a digital logic circuit reaches or exceeds 45MHZ ~ 50MHZ, and the circuit operating above this frequency has already occupied a certain portion of the entire electronic system (say 1/3), it is called a high-speed circuit. The following is about R5775G High-speed PCB related, I hope to help you better understand R5775G High-speed PCB.
High-frequency substrates, satellite systems, mobile phone receiving base stations and other communication products must use high-frequency circuit boards, which will inevitably develop rapidly in the next few years, and high-frequency substrates will be in large demand. The following is about Astra MT77 PCB related, I hope to help you better understand Astra MT77 PCB.
The success of a product depends on its internal quality. Second, it takes into account the overall beauty. Both are perfect to be considered successful. On a PCB board, the layout of the components needs to be balanced, dense and orderly, not top-heavy or heavy. The following is about 36 Layer 8MM Thick Megtron4 PCB related, I hope to help you better understand 36 Layer 8MM Thick Megtron4 PCB.
